1KG=2.2LB 1INCH=25.4MM
| 概要 |
型号 |
|
unit |
CPCD50 |
CPCD60 |
CPCD60A |
CPCD70 |
CPCD70A |
|
动力类型 |
|
|
柴油 |
|
额定负载 Q |
|
kg/lb |
5000/11000 |
6000/13200 |
7000/15400 |
|
载荷中心距+C |
|
mm/in |
600/23.6 |
| 特性 |
提升高度 |
|
mm/in |
3000/118 |
|
|
自由提升高度+hz |
|
mm/in |
0 |
|
140/5.5 |
140/5.5 |
|
货叉尺寸 |
s*e*L |
mm/in |
1200*150*70/47.2*6*2.8 |
1200*150*70/47.2*6*2.8 |
|
门架倾斜角度 |
前/后 |
deg |
6/12 |
|
转弯半径 |
|
mm/in |
3300/130 |
3350/132 |
3360/132.3 |
|
地面中心距 |
驱动轴下 |
mm/in |
150/6 |
190/7.5 |
|
地面中心距 |
车体中部 |
mm/in |
320/12.6 |
| 性能 |
最小直角堆垛宽度 |
|
mm/in |
2432/95.7 |
2450/96.5 |
|
最大行驶速度 |
Empty |
km/h |
22 |
23 |
23 |
|
最大爬坡能力 |
满载 |
% |
22 |
| 尺寸 |
最大提升速度
|
满载 |
mm/s |
320 |
370 |
330 |
370 |
|
总长度
|
含货叉 |
mm/in |
4780/188.2 |
4805/189.2 |
|
总长度 |
不含货叉 |
mm/in |
3580/141 |
3605/142 |
|
总宽度 |
|
mm/in |
1910/75.2 |
1995/78.5 |
| 车体 |
门架下降最低高度 |
|
mm/in |
2760/108.7 |
2625/103.3 |
|
提升时总高度 |
|
mm/in |
4374/172.2 |
|
前轮胎 |
|
|
8.25-15-14PR |
|
后轮胎 |
|
|
8.25-15-14PR |
| 发动机 |
轴距 |
|
mm/in |
2300/90.6 |
|
轮胎面 |
前轮胎 |
mm/in |
1400/55 |
1470/58 |
|
轮胎面 |
后轮胎 |
mm/in |
1534/60.4 |
1700/67 |
|
自重 |
|
kg/lb |
7800/17100 |
8500/18700 |
9350/20600 |
|
蓄电池 |
电压/类型 |
|
24V/2*6-QA-100a |
|
型号 |
|
|
LR4105G3 |
6102G3 |
LR4105G |
6102G3 |
|
气缸数缸径*行程(mm*mm) |
|
mm/in |
4-105*125 |
6-102*110 |
4-105*125 |
6-102*110 |
|
额定输出 |
|
KW |
58.8 |
64 |
60 |
64 |
|
标定转速 |
|
r/min |
2400 |
2200 |
2300 |
2200 |
|
额定扭距 |
|
N.m/r.p.m |
248/1700 |
285/1250 |
252/1800 |
285/1250 |
| 传动方式 |
标定燃油消耗 |
|
g/kW.h |
224 |
221 |
224 |
221 |
|
排气量 |
|
cc |
4.33 |
5.393 |
4.33 |
5.393 |
|
样式 |
|
|
Power shift |
|
产地 |
|
|
中国 |
|
档位 |
前/后 |
|
2/2 |
With heating cabinet to meet the special needs of customers
Electronic speed control
The seal ring of the hydraulic pump is imported from Western Germany.
The key parts of the Chinese engine are from Japan.
With shock absorption on all the diesel forklift
Features
F1: Much of the glass mantle opens up for convenient disassembly or maintenance.
F2:All controls have been ergonomically designed and are adjustable for easy, efficient operation and comfort.
F3:Built in heating supply, ideal for cold environment.
F4:The seat design conforms to the latest ergonomic consideration of good lateral body support with optimum freedom of movement. Air channels in the cushion surface improve seating comfort and reduce sliding. The two coil spring suspension under the seat is adjustable for drivers with different weights.
F5,F6:Rear view mirrors and high quality recessed lights.
F7:Strengthened glass and windshield wipers give the driver a clear view of the surroundings.
|
